About Aluminum-plastic composite panel
The aluminum-plastic composite panels are classified in surface treatment, there are granite/marble aluminum composite panels, brush finish aluminum composite panels, mirror finish aluminum composite panels ,wood aluminum composite panel and more.
The aluminum-plastic composite panel is composed of superior quality antirust sheets and high intensity polyethylene core sheets, and coated with worldclass fluorocarbon resin. Additionally, our composite panels are made strictly in accordance with international standard ACP production standard.
Specifications Of Aluminum-plastic Composite Panel
Aluminum composite panel standard size: 1220mm*2440mm*3mm and 1220mm*2440mm*4mm ( In addition, the sizes of the aluminum composite panel are available according to your requirement.)
Total thickness of the ACP: 3mm-6mm
Aluminum thickness: 0.05mm-0.5mm
Standard width : 1220mm , 1250mm
Non standard width:1000mm ,1500mm, 1550mm
Standard Length:2440mm , 2500mm
Non standard length: 2000mm , 3000mm
China ACP factory aluminum plastic composite panel
The aluminum thickness:
Aluminum thickness 0.06mm,0.08mm,0.10mm,0.12mm for 1220*2440*3mm
Aluminum thickness 0.06mm,0.08mm,0.10mm,0.12mm,0.15mm,0.18mm,0.21mm,0.25mm,0.30mm,
0.40mm,0.50mm for 1220*2440*4mm
Aluminum thickness0.21mm,0.3mm,0.4mm,0.5mm for Brush aluminum composite panel and Mirror aluminum composite panel.
Dimensional Tolerances of the aluminum composite panel
Thickness: -0.02mm/+0.02mm
Width:-0/+2mm
Length:-0/+4mm for 1000mm-4000mm -0/+6mm for 4001mm-6000mm
Feature of the aluminum composite panel /ACP
1.The aluminum composite panel have the economy.
Due to our adoption of high quality coatings, our aluminum composite panels are dispensed with frequent maintenance, thus saving a lot on maintenance cost. Hence, our composite panels are good decorative building material for high-rise buildings.
2.The aluminum composite panel have the durability
Fluorocarbon coated aluminum composite panels are characterized by long service life, good weather resistance, high heat resistance and wear resistance, and good resistance to pollution, and more.
3.The aluminum composite panel have the light weight and easy to process.
By adopting light weight aluminum alloy and superior quality plastics as primary raw material, aluminum composite panel is lighter than other types of decorative construction material. so it is easy to install and shortens installation period.
4.The aluminum composite panel is easy to install
Our aluminum composite panels are adaptable to various decoration requirements, because they are easy to be cut, grooved and bended.
5.The aluminum composite panel is easy to maintain
With regard to cities and regions with serious environment pollution, it is recommended to clean and maintain aluminum composite panels in a few year’s time. Our panels are easy to be cleaned. They can be cleaned by neutral cleaning agent and clean water, and come out to be fairly new after cleaned.
6.The aluminum composite panel is fireproofing
The exterior aluminum sheet of aluminum composite panels can effectively protect interior PE core material,because it can prevent heat conduction at the initial stage of combustion. The flame resistance of our aluminum plastic composite panels has reached international standard.
Application scope of the aluminum plastic composite panel/ACP
-Gas piping, cables, building materials, etc .This product fills a gap in the domestic construction materials field,with performance in dexessuperior to panels manufactured overseas.
-Curtain wall decoration for buildings where security is important, such as airports, hospitals and research centers
-Curtain wall boards for outside walls of normal buildings
-Renovations of old buildings and movable houses
-Reformation and decoration for indoor walls, ceilings,bathrooms,kitchens and balconies
-Facades
-Billboards, exhibition desks and notice boards
-Wall boards and ceilings for tunnels
-Materials for industrial application, car and ship bodies
